Danfoss VLT AutomationDrive Programming Guide

4-57 Warning Feedback High
Range: Function:
999999.999
ReferenceFeed-
backUnit*
[Application
dependant]
Enter the upper feedback
limit. When the feedback
exceeds this limit, the display
reads Feedb High. The signal
outputs can be programmed
to produce a status signal on
terminal 27 or 29 (FC 302
only) and on relay output 01
or 02 (FC 302 only).
4-58 Missing Motor Phase Function
Displays an alarm in the event of a missing motor phase (alarm
30, 31 or 32). Select disabled for no missing motor phase alarm.
It is strongly recommended to make an active setting to avoid
motor damage.
Option: Function:
[0] * Disabled No alarm is displayed if a
missing motor phase
occurs.
[1] Trip 100 ms Trips after 100 ms. Select
100ms for fast detection of
missing motor phase.
[2] Trip 1000 ms Trips after 1000ms. Select
1000ms for slow detection
of missing motor phase.
[3] Trip 100ms 3ph
detec.
NOTE!
This parameter cannot be adjusted while the motor is
running.
3.6.4 4-6* Speed Bypass
Some systems call for avoiding certain output frequencies
or speeds due to resonance problems in the system. A
maximum of four frequency or speed ranges can be
avoided.
4-60 Bypass Speed From [RPM]
Array [4]
Range: Function:
Application
dependent*
[Application
dependant]
Some systems call for
avoiding certain output
speeds due to resonance
problems in the system.
Enter the lower limits of the
speeds to be avoided.
4-61 Bypass Speed From [Hz]
Array [4]
Range: Function:
Size related* [ 0.0 - par. 4-14 Hz]
4-62 Bypass Speed To [RPM]
Array [4]
Range: Function:
Application
dependent*
[Application
dependant]
Some systems call for
avoiding certain output
speeds due to resonance
problems in the system.
Enter the upper limits of
the speeds to be avoided.
4-63 Bypass Speed To [Hz]
Array [4]
Range: Function:
Application
dependent*
[Application
dependant]
Some systems call for
avoiding certain output
speeds due to resonance
problems in the system.
Enter the upper limits of
the speeds to be avoided.
Parameter Descriptions FC 300 Programming Guide
3-48 MG33MD22 - VLT
®
is a registered Danfoss trademark
3
3
