12-13 Link Speed
Option: Function:
[2] 100 Mbps
12-14 Link Duplex
Option: Function:
Forces the duplex for each port to full or half
duplex. If 12-12 Auto Negotiation is set to: ON,
this parameter is read-only.
[0] Half duplex
[1] * Full duplex
3.13.3 12-2* Process Data
12-20 Control Instance
Range: Function:
[None, 20, 21, 100,
101, 103]
Read only. Displays the originator-to-
target connection point. If no CIP
connection is present, “None” is
displayed.
12-21 Process Data Config Write
Range: Function:
[[0–9] PCD read 0–9] Configuration of readable process data.
NOTE!
To configure 2-word (32-bit) parameters for read/write, use
two consecutive arrays in 12-21 Process Data Config Write
and 12-22 Process Data Config Read.
12-22 Process Data Config Read
Range: Function:
[[0–9] PCD read 0–9] Configuration of readable process data.
12-23 Process Data Config Write Size
Range: Function:
16* [1 - 32 ] Sets the number of bits being sent from the drive
as process data. The setting counts from right
(LSB). The value 1 means that only the least
significant bit of the signal will be transferred
from the drive.
12-24 Process Data Config Read Size
Range: Function:
16* [1 - 32 ] Sets the number of bits being sent to the drive
as process data. The setting counts from right
(LSB). The value 1 means that only the least
significant bit of the signal will be transferred to
the drive. The preceding bits will be set to zero.
12-27 Primary Master
Range: Function:
0* [0 -
4294967295 ]
Controls the master’s access to the process
data. The value zero (0.0.0.0) means that
other masters can take control of the drive
immediately if the connection is lost or
closed. Setting an IP number means that
only a master with this value can establish
a connection for controlling the drive. In
systems with backup masters, this
parameter should be left to the value zero
(0.0.0.0).
12-28 Store Data Values
Option: Function:
This parameter activates a function that stores
all parameter values in the non-volatile
memory (EEPROM) thus retaining parameter
values at power-down.
The parameter returns to “Off”.
[0] * Off The store function is inactive.
[1] Store all
set-ups
All parameter value will be stored in the non-
volatile memory in all four set-ups.
12-29 Store Always
Option: Function:
Activates function that will always store received
parameter data in non-volatile memory (EEPROM).
[0] * Off
[1] On
Parameter Descriptions FC 300 Programming Guide
3-106 MG33MD22 - VLT
®
is a registered Danfoss trademark
3
3
