4.1.2 Active/Inactive Parameters in Different Drive Control Modes
+ = active
- = not active
1-10 Motor Construction
AC motor PM Non-salient Motor
1-01 Motor Control Principle
U/f mode VVC+
Flux open-
loop
Flux closed-
loop
U/f mode
Flux
open-
loop
Flux
closed-
loop
1-00 Configuration Mode
[0] Speed Open-loop + + + -
[1] Speed Closed-loop - + - +
[2] Torque - - - +
[3] Process + + + -
[4] Torque Open-loop - + - -
[5] Wobble + + + +
[6] Surface Winder + + + -
[7] Ext. PID Open-loop + + + -
[8] Ext. PID Closed-loop - + - +
1-02 Flux Motor Feedback Source
- - - +
1-03 Torque Characteristics
-
+
see 1, 2, 3)
+
see 1, 3, 4)
+
see 1, 3, 4)
1-04 Overload Mode
+ + + + + + +
1-05 Local Mode Configuration
+ + + + + + +
1-06 Clockwise Direction
+ + + + + + +
1-20 Motor Power [kW]
(Par. 023 = International)
+ + + +
1-21 Motor Power [HP]
(Par. 023 = US)
+ + + +
1-22 Motor Voltage
+ + + +
1-23 Motor Frequency
+ + + +
1-24 Motor Current
+ + + +
1-25 Motor Nominal Speed
+ + + +
1-26 Motor Cont. Rated Torque
- - - - + + +
1-29 Automatic Motor Adaptation (AMA)
+ + + +
1-30 Stator Resistance (Rs)
+ + + + +
1-31 Rotor Resistance (Rr)
-
+
see 5)
+ +
1-33 Stator Leakage Reactance (X1)
+ + + + +
1-34 Rotor Leakage Reactance (X2)
-
+
see 5)
+ +
1-35 Main Reactance (Xh)
+ + + + +
1-36 Iron Loss Resistance (Rfe)
- - + + - - -
1-37 d-axis Inductance (Ld)
- - - - + +
1-39 Motor Poles
+ + + +
1-40 Back EMF at 1000 RPM
- - - - + + +
1-41 Motor Angle Offset
- - - - +
1) Constant torque
2) Variable torque
3) AEO
4) Constant power
5) Used in flystart
