6-50 Terminal 42 Output
Option: Function:
[134] Torq.% lim
4-20 mA
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
[135] Torq.%
nom 4-20
mA
The torque setting is related to the motor
torque setting.
[136] Power
4-20mA
Taken from 1-20 Motor Power [kW]
[137] Speed
4-20mA
Taken from 3-03 Maximum Reference. 20mA =
Value in 3-03 Maximum Reference.
[138] Torque
4-20mA
Torque reference related to 160% torque.
[139] Bus ctrl.
0-20 mA
An output value set from serial communi-
cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[140] Bus ctrl.
4-20 mA
An output value set from serial communi-
cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[141] Bus ctrl
0-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[142] Bus ctrl
4-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[149] Torque %
lim 4-20mA
Analog output at zero torque = 12mA.
Motoric torque will increase the output
current to max torque limit 20mA (set in
4-16 Torque Limit Motor Mode).
Generative torque will decrease the output to
torque limit Generator Mode (set in
4-17 Torque Limit Generator Mode)
Ex: 4-16 Torque Limit Motor Mode : 200% and
4-17 Torque Limit Generator Mode: 200%.
20mA = 200% Motoric and 4mA = 200%
Generatoric.
[150] Max Out Fr
4-20mA
0hz = 0mA,4-19 Max Output Frequency =
20mA.
6-51 Terminal 42 Output Min Scale
Range: Function:
0.00 %* [0.00 - 200.00 %]
6-52 Terminal 42 Output Max Scale
Range: Function:
100.00 %* [0.00 - 200.00 %]
20
mA
/
desired
maximum
current
x
100 %
i
.
e
. 10
mA
:
20
10
x
100 = 200 %
6-53 Terminal 42 Output Bus Control
Range: Function:
0.00 %* [0.00 - 100.00 %]
6-54 Terminal 42 Output Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %]
6-55 Analog Output Filter
Option: Function:
The following readout analog parameters from
selection in 6-50 Terminal 42 Output have a filter
selected when 6-55 Analog Output Filter is on:
Selection 0-20mA 4-20mA
Motor current (0 - I
max
) [103] [133]
Torque limit (0 - T
lim
) [104] [134]
Rated torque (0 - T
nom
) [105] [135]
Power (0 - P
nom
) [106] [136]
Speed (0 - Speedmax) [107] [137]
[0] * Off Filter off
[1] On Filter on
3.8.7 6-6* Analog Output 2 MCB 101
Analog outputs are current outputs: 0/4 - 20mA. Common
terminal (terminal X30/8) is the same terminal and
electrical potential for analog common connection.
Resolution on analog output is 12 bit.
6-60 Terminal X30/8 Output
Option: Function:
Select the function of Terminal X30/8 as an
analog current output. Depending on the
selection the output is either a 0-20mA or
4-20mA output. The current value can be
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-73
3
3
