Danfoss VLT AutomationDrive Programming Guide

6-60 Terminal X30/8 Output
Option: Function:
read out in LCP in 16-65 Analog Output 42
[mA].
[0] * No
operation
When no signal on the analog output.
[52] MCO
0-20mA
[100] Output
frequency
0hz = 0mA; 100hz = 20mA.
[101] Reference
3-00 Reference Range [Min - Max] 0% = 0mA;
100% = 20mA
3-00 Reference Range [-Max - Max] -100% =
0mA; 0% = 10mA; +100% = 20 mA
[102] Feedback
[103] Motor
current
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20mA.
Example: Inverter norm current (15 hp [11
kW]) = 24 A. 160% = 38.4 A. Motor norm
current = 22 A Readout 11.46mA.
20
mA x 22 A
38.4 A
= 11.46 mA
If the norm motor current is equal to 20mA,
the output setting of 6-62 Terminal X30/8
Max. Scale is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
= 175 %
[104] Torque rel
to limit
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
[105] Torq relate
to rated
The torque is related to the motor torque
setting.
[106] Power
Taken from 1-20 Motor Power [kW].
[107] Speed
Taken from 3-03 Maximum Reference. 20mA =
value in 3-03 Maximum Reference
[108] Torque Torque reference related to 160% torque.
[109] Max Out
Freq
In relation to 4-19 Max Output Frequency.
[113] PID
Clamped
Output
[119] Torque %
lim
[130] Output
freq.
4-20mA
0hz = 4mA, 100hz = 20mA
6-60 Terminal X30/8 Output
Option: Function:
[131] Reference
4-20mA
3-00 Reference Range [Min-Max] 0% = 4mA;
100% = 20mA
3-00 Reference Range [-Max-Max] -100% =
4mA; 0% = 12 mA; +100% = 20 mA
[132] Feedback
4-20mA
[133] Motor cur.
4-20mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20mA.
Example: Inverter norm current (15 hp [11
kW]) = 24 A. 160% = 38.4 A. Motor norm
current = 22 A Readout 11.46mA.
16
mA x 22 A
38.4 A
= 9.17 mA
If the norm motor current is equal to 20mA,
the output setting of 6-62 Terminal X30/8
Max. Scale is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
= 175 %
[134] Torq.% lim
4-20 mA
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
[135] Torq.%
nom 4-20
mA
The torque setting is related to the motor
torque setting.
[136] Power
4-20mA
Taken from 1-20 Motor Power [kW]
[137] Speed
4-20mA
Taken from 3-03 Maximum Reference. 20mA =
Value in 3-03 Maximum Reference.
[138] Torque
4-20mA
Torque reference related to 160% torque.
[139] Bus ctrl.
0-20 mA
An output value set from serial communi-
cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[140] Bus ctrl.
4-20 mA
An output value set from serial communi-
cation bus process data. The output will work
independently of internal functions in the
Adjustable frequency drive.
[141] Bus ctrl
0-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[142] Bus ctrl
4-20mA t.o.
4-54 Warning Reference Low defines the
behavior of the analog output in case of bus
timeout.
[149] Torque %
lim 4-20mA
Torque% Lim 4-20mA: Torque reference.
3-00 Reference Range [Min-Max] 0% = 4mA;
100% = 20mA
Parameter Descriptions FC 300 Programming Guide
3-74 MG33MD22 - VLT
®
is a registered Danfoss trademark
3
3
