16-16 Torque [Nm]
Range: Function:
from when an input changes value to when
the data readout values change.
16-17 Speed [RPM]
Range: Function:
0 RPM* [-30000 -
30000 RPM]
View the actual motor RPM. In open-
loop or closed-loop process control, the
motor RPM is estimated. In speed
closed-loop modes, the motor RPM is
measured.
16-18 Motor Thermal
Range: Function:
0 %* [0 - 100 %] View the calculated thermal load on the
motor. The cut-out limit is 100%. The basis
for calculation is the ETR function selected in
1-90 Motor Thermal Protection.
16-19 KTY sensor temperature
Range: Function:
0 C* [0 - 0 C]
16-20 Motor Angle
Range: Function:
0* [0 - 65535 ] View the current encoder/resolver angle offset
relative to the index position. The value range
of 0-65535 corresponds to 0-2*pi (radians).
16-21 Torque [%] High Res.
Range: Function:
0.0 %* [-200.0 - 200.0 %]
16-22 Torque [%]
Range: Function:
0 %* [-200 - 200 %] Value shown is the torque as a
percentage of nominal torque, with sign,
applied to the motor shaft.
16-25 Torque [Nm] High
Range: Function:
0.0
Nm*
[-200000000.0 -
200000000.0 Nm]
View the torque value with sign,
applied to the motor shaft. Some
motors supply more than 160%
torque. Consequently, the min. value
and the max. value will depend on
the max. motor current as well as the
motor used. This specific readout has
been adapted to show higher values
than the standard readout in
16-16 Torque [Nm].
3.17.2 16-3* Drive Status
16-30 DC Link Voltage
Range: Function:
0 V* [0 - 10000 V] View a measured value. The value is filtered
with an 30ms time constant.
16-32 Brake Energy /s
Range: Function:
0.000 kW* [0.000 - 10000.000
kW]
View the braking energy
transmitted to an external brake
resistor, stated as an instan-
taneous value.
16-33 Brake Energy /2 min
Range: Function:
0.000 kW* [0.000 -
10000.000 kW]
View the braking energy
transmitted to an external brake
resistor. The mean power is
calculated on an average basis for
the most recent 120 sec.
16-34 Heatsink Temp.
Range: Function:
0 °C* [0 - 255 °C]
16-35 Inverter Thermal
Range: Function:
0 %* [0 - 100 %] View the percentage load on the inverter.
16-36 Inv. Nom. Current
Range: Function:
Application
dependent*
[0.01 -
10000.00 A]
View the inverter nominal
current, which should match the
nameplate data on the
connected motor. The data are
used for calculation of torque,
motor protection, etc.
Application
dependent*
[0.01 -
10000.00 A]
View the inverter nominal
current, which should match the
nameplate data on the
connected motor. The data are
used for calculation of torque,
motor protection, etc.
16-37 Inv. Max. Current
Range: Function:
Application
dependent*
[0.01 -
10000.00 A]
View the inverter maximum
current, which should match the
nameplate data on the
Parameter Descriptions FC 300 Programming Guide
3-142 MG33MD22 - VLT
®
is a registered Danfoss trademark
