13-01 Start Event
Option: Function:
[4] On reference
On reference [4] The motor is running
on reference.
[5] Torque limit
Torque limit [5] The torque limit, set in
4-16 Torque Limit Motor Mode or
4-17 Torque Limit Generator Mode, has
been exceeded.
[6] Current limit
Current limit [6] The motor current
limit, set in 4-18 Current Limit, has been
exceeded.
[7] Out of current
range
Out of current range [7] The motor
current is outside the range set in
4-18 Current Limit.
[8] Below I low
Below I low [8] The motor current is
lower than set in 4-50 Warning Current
Low.
[9] Above I high
Above I high [9] The motor current is
higher than set in 4-51 Warning Current
High.
[10] Out of speed
range
Out of speed range [10] The speed is
outside the range set in 4-52 Warning
Speed Low and 4-53 Warning Speed
High.
[11] Below speed low
Below speed low [11] The output speed
is lower than the setting in
4-52 Warning Speed Low.
[12] Above speed
high
Above speed high [12] The output
speed is higher than the setting in
4-53 Warning Speed High.
[13] Out of feedb.
range
Out of feedb. Range [13] The feedback
is outside the range set in
4-56 Warning Feedback Low and
4-57 Warning Feedback High.
[14] Below feedb. low
Below feedb. Low [14] The feedback is
below the limit set in 4-56 Warning
Feedback Low.
[15] Above feedb.
high
Above feedb. High [15] The feedback is
above the limit set in 4-57 Warning
Feedback High.
[16] Thermal warning
Thermal warning [16] The thermal
warning turns on when the
temperature exceeds the limit in the
motor, the Adjustable frequency drive,
the brake resistor or the thermistor.
[17] Mains out of
range
Mains out of range [17] The AC line
voltage is outside the specified voltage
range.
13-01 Start Event
Option: Function:
[18] Reversing
Reverse [18] The output is high when
the Adjustable frequency drive is
running counter clockwise (the logical
product of the status bits “running”
AND “reverse”).
[19] Warning
Warning [19] A warning is active.
[20] Alarm (trip)
Alarm (trip) [20] A (trip) alarm is active.
[21] Alarm (trip lock)
Alarm (trip lock) [21] A (Trip lock) alarm
is active.
[22] Comparator 0
Comparator 0 [22] Use the result of
comparator 0.
[23] Comparator 1
Comparator 1 [23] Use the result of
comparator 1.
[24] Comparator 2
Comparator 2 [24] Use the result of
comparator 2.
[25] Comparator 3
Comparator 3 [25] Use the result of
comparator 3.
[26] Logic rule 0
Logic rule 0 [26] Use the result of logic
rule 0.
[27] Logic rule 1
Logic rule 1 [27] Use the result of logic
rule 1.
[28] Logic rule 2
Logic rule 2 [28] Use the result of logic
rule 2.
[29] Logic rule 3
Logic rule 3 [29] Use the result of logic
rule 3.
[33] Digital input DI18
Digital input DI18 [33] Use the result of
digital input 18.
[34] Digital input DI19
Digital input DI19 [34] Use the result of
digital input 19.
[35] Digital input DI27
Digital input DI27 [35] Use the result of
digital input 27.
[36] Digital input DI29
Digital input DI27 [35] Use the result of
digital input 29.
[37] Digital input DI32
Digital input DI32 [37] Use the result of
digital input 32.
[38] Digital input DI33
Digital input DI33 [38] Use the result of
digital input 33.
[39] Start command
Start command [39] A start command is
issued.
[40] Drive stopped
Drive stopped [40] A stop command
(Jog, Stop, Qstop, Coast) is issued –
and not from the SLC itself.
[41] Reset Trip
Reset Trip [41] A reset is issued
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-111
