Danfoss VLT AutomationDrive Programming Guide

Failure Alarm Off Warning Trip Trip Lock
10 V low 1 X D
24 V low 47 X D
1.8V supply low 48 X D
Voltage limit 64 X D
Ground fault during ramping 14 D X
Ground fault 2 during cont.
operation
45 D X
Torque Limit 12 X D
Overcurrent 13 X D
Short Circuit 16 X D
Heatsink temperature 29 X D
Heatsink sensor 39 X D
Control card temperature 65 X D
Power card temperature 6
2)
X D
Heatsink temperature
1)
244 X D
Heatsink sensor
1)
245 X D
Power card temperature
1)
247
Table 3.3 Table for selection of choice of action when selected alarm appears
D = Default setting. x = possible selection.
1) Only high power drives
In FC small and medium A69 is only a warning
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-135
3
3
