0-20 Display Line 1.1 Small
Option: Function:
[1675] Analog In X30/11 Actual value at input X30/11
either as reference or protection
value.
[1676] Analog In X30/12 Actual value at input X30/12
either as reference or protection
value.
[1677] Analog Out X30/8
[mA]
Actual value at output X30/8 in
mA. Use 6-60 Terminal X30/8
Output to select the value to be
shown.
[1678] Analog Out X45/1
[mA]
[1679] Analog Out X45/3
[mA]
[1680] Fieldbus CTW 1 Control word (CTW) received
from the bus master.
[1682] Fieldbus REF 1 Main reference value sent with
control word from the bus
master.
[1684] Comm. Option STW Extended serial communication
option status word.
[1685] FC Port CTW 1 Control word (CTW) received
from the bus master.
[1686] FC Port REF 1 Status word (STW) sent to the
bus master.
[1690] Alarm Word One or more alarms in a Hex
code.
[1691] Alarm Word 2 One or more alarms in a Hex
code.
[1692] Warning Word One or more warnings in a Hex
code.
[1693] Warning Word 2 One or more warnings in a Hex
code.
[1694] Ext. Status Word One or more status conditions in
a Hex code.
[1836] Analog Input X48/2
[mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
[1890] Process PID Error
[1891] Process PID Output
[1892] Process PID Clamped
Output
[1893] Process PID Gain
Scaled Output
0-20 Display Line 1.1 Small
Option: Function:
[3019] Wobble Delta Freq.
Scaled
[3110] Bypass Status Word
[3111] Bypass Running
Hours
[3401] PCD 1 Write to MCO
[3402] PCD 2 Write to MCO
[3403] PCD 3 Write to MCO
[3404] PCD 4 Write to MCO
[3405] PCD 5 Write to MCO
[3406] PCD 6 Write to MCO
[3407] PCD 7 Write to MCO
[3408] PCD 8 Write to MCO
[3409] PCD 9 Write to MCO
[3410] PCD 10 Write to MCO
[3421] PCD 1 Read from
MCO
[3422] PCD 2 Read from
MCO
[3423] PCD 3 Read from
MCO
[3424] PCD 4 Read from
MCO
[3425] PCD 5 Read from
MCO
[3426] PCD 6 Read from
MCO
[3427] PCD 7 Read from
MCO
[3428] PCD 8 Read from
MCO
[3429] PCD 9 Read from
MCO
[3430] PCD 10 Read from
MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master
Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master
Velocity
[3460] Synchronizing Status
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-7
