E-GENIUS
92
AV500/AV900 2D CAMERA
2. Enter the appropriate information in the form as described below:
Operating Mode Selections
Select one of the following modes:
“Packtrack Mode” on page 93 is a patented operating mode for Datalogic devices used to
read and correctly assign codes read on different parcels when placed in the camera reading
area at the same time. The technology allows for smaller gaps between packages. It can also be
used in bidirectional systems, in which you may want to read codes going forward or reverse.
“Online Mode” on page 100 in Online operating mode, the reading phase is defined as the
time between a Phase ON and Phase OFF event. The Phase events can be signals coming from
one or two external presence sensors connected to the camera inputs or a message start/stop
strings sent from the host over the serial interface or Ethernet input.
“Continuous Mode” on page 103 is continuous image / frame acquisition mode with
immediate decode result processing and transmission. Frames are acquired at the rate
selected. Suppression filters are available for eliminating duplicate decode results within a
single frame and across multiple frames and can be configured either based on time or
distance. When using a distance based suppression filter, distance can be based on a physical
encoder where the clock time to timeout will be dependent on how fast the belt is running or
where time will be based on an internal tach set to 1 meter per second. An option for code
replication is also available where a decode result is replicated or not suppressed when the
same code value is decoded but the code types are different.
Image Saving does not work in Continuous Mode.
