E-GENIUS
138
AV500/AV900 2D CAMERA
Enable Precise Label Orientation
Select the check box to enable precise label orientation. This option tells the decode engine to
spend more processing time locating the center point and bounding box around the barcode
symbol.
Code and Background Color
Select Black on White, White on Black, or Both from the drop-down list to match the kind of
barcodes read by the system.
Enable Strict Process Time Limit
Select the check box to enable a processing time to be set. Specify the maximum amount of
time the decoder can spend processing a single image. This may be used to prevent the
decoder from spending too much time on a noisy image
Strict Process Time Limit
Enter an amount of time in ms to limit your camera’s processing time to.
Advanced Localizer Settings
Enable Advanced Localizer
Select the check box to enable the advanced localizer options.
Advanced Localizer Usage
The camera employs hardware acceleration to locate possible bar codes. This option specifies
for which symbologies the hardware acceleration should be used
The following parameters allow you to define an ROI or Region of Interest for the decoder. This
is a region where you will find the bar code. You may want to define a different Max 1D region
than the Max 2D region because you may want one to be larger than the other. The parameters
below allow you define these individually.
ROI Threshold
Enter a Region of Interest Threshold.
Maximum 1D Regions
Enter the necessary 1D Region.
Maximum 2D Regions
Enter the necessary 2D Region.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values.
This option may increase processing time which may create no reads
DO NOT change this parameter unless directed by Datalogic Support.
