ADVANCED FORMATTER | MESSAGE BUILDER
PRODUCT REFERENCE GUIDE
159
•Day: Indicates day of the month the code was scanned
•
Month: Indicates month the code was scanned
•
Year: Indicates year the code was scanned
•
Protocol Index: Indicates the programmed protocol index string data
•Parcel Length: Indicates the approximate length of the package
•
Parcel Width: Indicates the approximate width of the package
•
Parcel Height: Indicates the approximate height of the package
•
Parcel Volume: Indicates the approximate volume of the package
•
Parcel Orientation Angle: Indicates the angle of the package
•
Parcel Isolated: indicates it is not a side-by-side condition as detected by the
Dimensioning system.
•
Image Filename: Includes the filename of the image
STRING ITEMS:
Link to Code
Select Disabled, Previous Code, or Next Code from the drop-down list.
•
Disabled: A code will not be linked to this text string
•
Previous Code: The text string will be linked to the previous generated code
•
Next Code: The text string will be linked to the next generated code
Miscellaneous String
Click to activate the “The Text Entry Tool” on page 81 and enter a code related string.
3. When you have finished making changes, click Update to save or click Reset to
revert to the previously saved values
Length, Width, Height, and Volume are only used if there is a DM3610 in your system.
