354
AV500/AV900 2D CAMERA
APPENDIX C
AV500 TIMING AND DISTANCE DIAGRAMS
This document identifies the distance/timing between the photo sensor, position sen-
sor(s), dimensioner, etc. and the AV500/AV900 camera. It includes:
Distance from trigger source to position sensor
Distance from position sensor to AV500
DM3610/Dual Headed scan line to DM3610 focus data transmit point
Three AV500s and a Single S85 Configuration
All configurations use a photo sensor as the trigger source. The position sensors identi-
fied in the document include:
“Fixed Focus Single Trigger Source” on page 355
“Focusing with a Light Curtain” on page 356
“Focusing with a Light Curtain and S85” on page 357
“Focusing with S85’s” on page 358
“Focusing with a Single DM3610” on page 359
“Focusing with a Dual DM3610 System” on page 360
