PRODUCT REFERENCE GUIDE
361
APPENDIX D
BI-DIRECTIONAL SETUP
With the release of Decoder and RTP SW Versions 0.0.0.100 the AV500/AV900 now sup-
ports bi-directional conveyor travel. A Datalogic Bidirectional s
ystem accommodates an
application where the customer can change the direction of the conveyor. To accommo-
date a Bidirectional system, an additional photocell is r
equired, as well as other special
equipment and software settings, as follows:
• Special tachometer bracket to more securely fasten the tachometer to the con-
veyor
• An additional photocell to signal in the reverse direction
• A customer supplied switch (relay) to indicate to the system in which direction the
conv
eyor is going
• Bidirectional software settings
• SC5100 Bidirectional software settings
