INSTALLING THE DEFLECTION MIRROR
PRODUCT REFERENCE GUIDE
43
5. Rotate the mirror brackets so that the correct skew angle slot as shown on the
bracket (15 or 45 degrees).
6. When in position, tighten center and outer ring nuts and attach two additional
bolts and nuts in place and tighten as shown in previous diagrams.
7. Now mount the mirror to the bracket.
To prevent mirror bowing or flexing, leave enough play with the rising bracket so if top
and bottom (or left and right) brackets are not aligned you do not damage the mirror.
