1108 | VLAN

www.dell.com | support.dell.com

Enable VLAN Interface Counters

Use a Native VLAN on Trunk Ports is available only on platform: e

Note: VLAN egress counters might be higher than expected because source-suppression drops are

counted.

Task Command Syntax Command Mode

Configure ingress, egress or both counters

for VLAN interfaces.

enable vlan-counter [ingress | egress | all] CONFIGURATION
