40 | Configuration Fundamentals
www.dell.com | support.dell.com
The do Command
Enter an EXEC mode command from any CONFIGURATION mode (CONFIGURATION, INTERFACE,
SPANNING TREE, etc.) without returning to EXEC mode by preceding the EXEC mode command with
the command
do. Figure 2-4 illustrates the do command.
Figure 2-4. Using the do Command
Undoing Commands
When you enter a command, the command line is added to the running configuration file. Disable a
command and remove it from the running-config by entering the original command preceded by the
command
no. For example, to delete an ip address configured on an interface, use the no ip address
ip-address
command, as shown in Figure 2-5.
Figure 2-5. Undoing a command with the no Command
Layer 2 protocols are disabled by default. Enable them using the no disable command. For example, in
PROTOCOL SPANNING TREE mode, enter
no disable to enable Spanning Tree.
Note: The following commands cannot be modified by the do command: enable, disable, exit, and
configure.
Note: Use the help or ? command as discussed in Obtaining Help command to help you construct the
“no” form of a command.
FTOS(conf)#do show linecard all
-- Line cards --
Slot Status NxtBoot ReqTyp CurTyp Version Ports
---------------------------------------------------------------------------
0 not present
1 not present
2 online online E48TB E48TB 1-1-463 48
3 not present
4 not present
5 online online E48VB E48VB 1-1-463 48
“do” form of show command
FTOS(conf)#interface gigabitethernet 4/17
FTOS(conf-if-gi-4/17)#ip address 192.168.10.1/24
FTOS(conf-if-gi-4/17)#show config
!
interface GigabitEthernet 4/17
ip address 192.168.10.1/24
no shutdown
FTOS(conf-if-gi-4/17)#no ip address
FTOS(conf-if-gi-4/17)#show config
!
interface GigabitEthernet 4/17
IP address assigned
“no” form of IP address command
IP address removed
