Content Addressable Memory | 289
To change the CAM profile on the entire system:
CAM Allocation
User Configurable CAM Allocations is available on platforms: c s
Allocate space for IPV4 ACLs and QoS regions, and IPv6 6 ACLs and QoS regions on the C-Series and
S-Series by using the
cam-acl command in CONFIGURATION mode.
The CAM space is allotted in FP blocks. The total space allocated must equal 13 FP blocks. The default
CAM Allocation settings on a C-Series system are:
• L3 ACL (ipv4acl): 5
• L2 ACL(l2acl) : 6
• IPv6 L3 ACL (ipv6acl): 0
• L3 QoS (ipv4qos): 1
• L2 QoS (l2qos): 1
• L2PT (l2pt): 0
• MAC ACLs (ipmacacl): 0
• ECFMACL (ecfmacl): 0
• VMAN QoS (vman-qos): 0
• VMAN Dual QoS (vman-dual-qos): 0
Step Task Command Syntax Command Mode
1
Select a CAM profile
.
cam-profile profile microcode
microcode
CONFIGURATION
Note: If selecting a cam-profile for VRF (cam-profile ipv4-vrf or ipv4-v6-vrf), implement the command
in the CONFIGURATION mode only. If you use EXEC Privilege mode, the linecards may go into an
error state.
2
Save the running-configuration.
copy running-config
startup-config
EXEC Privilege
3
Verify that the new CAM profile will be
written to the CAM on the next boot.
show cam-profile summary
EXEC Privilege
4
Reload the system.
reload
EXEC Privilege
Note: The ipmacacl region was introduced for Secure DHCP. These ACL are not created through CLI,
but rather are system generated from the DHCP snooping table. Whenever a new DHCP client is
assigned an IP, and ip dhcp snooping source-address-validation ipmac is configured on the interface
connected to the client, a single ACL is installed on the interface to permit (only) the source IP and source
MAC pair.
