Dell Force10 C150 - Neighbor Shutdown

234 | Border Gateway Protocol IPv4 (BGPv4)
www.dell.com | support.dell.com
Figure 10-20. Command example: show config (peer-group enabled
To disable a peer group, use the neighbor peer-group-name shutdown command in the CONFIGURATION
ROUTER BGP mode. The configuration of the peer group is maintained, but it is not applied to the peer
group members. When you disable a peer group, all the peers within the peer group that are in
ESTABLISHED state are moved to IDLE state.
Use the show
ip bgp peer-group command in EXEC Privilege mode (Figure 10-21) to view the status of
peer groups.
FTOS(conf-router_bgp)#neighbor zanzibar no shutdown
FTOS(conf-router_bgp)#show config
!
router bgp 45
bgp fast-external-fallover
bgp log-neighbor-changes
neighbor zanzibar peer-group
neighbor zanzibar no shutdown
neighbor 10.1.1.1 remote-as 65535
neighbor 10.1.1.1 shutdown
neighbor 10.14.8.60 remote-as 18505
neighbor 10.14.8.60 no shutdown
FTOS(conf-router_bgp)#
Enabling neighbor
zanzibar
