AUTO HOLD status indicator lamp*
This lamp will come on when the AUTO HOLD is
enabled.
EPB ON indicator lamp
When the ENGINE START/STOP button is in
“ON” position, the indicator lamp shall come on
immediately. If the EPB is not activated, the
lamp will go out after a few seconds. If the EPB
is activated, the lamp will stay on until the EPB is
released. If the lamp does not come on, please
contact the authorized dealer for inspection.
(See page 135 and 136 for details)
When the EPB is activated, the EPB ON
indicator lamp will come on.
When the AUTO HOLD function is in operation,
the EPB indicator lamp (green) will come
on.
HDC indicator lamp*
When the HDC works, this indicator lamp will
come on. The vehicle will go downhill at a
constant low speed.
ACC READY indicator lamp*(gray)
This lamp will come on when the ACC is ready.
(See page 147 for details)
ACC ON indicator lamp*(green)
This lamp will come on when the ACC controls
the vehicle. (See page 147 for details)
LDW indicator lamp*(green)
This lamp will come on when the LDW is turned
on through MP5 system. (See page 155 for
details)
LKA indicator lamp*(green)
This lamp will come on when the LKA is turned
on through MP5 system. (See page 155 for
details)
/ / ICA indicator lamp*
When the ICA is in different working modes, the
corresponding indicator lamps on the instrument
cluster will come on:
On - the system is ready;
On - the system is activated;
On - the system is in a degraded operating
state.
(See page 162 for details)
/ / IHBC ON indicator lamp*
When the IHBC is in different working modes,
the corresponding indicator lamps on the
instrument cluster will come on:
On - the system is ready;
On - the system is working;
On - the system is faulty;
JA OFF indicator lamp*
When the “JA” function is turned off via MP5, the
JA OFF indicator lamp will come on, and JA will
be turned off at this time.
