181
, Electrical system
chap.4
(6) Eject Fan Speed Adjustment
1. Adjustment of Eject Fan Speeds 1-5
1) Access HELP mode H-01, and press the PRINT key.
2) Press the and/or key to select the Eject fan
speed item.
3) Press the and/or PRINTING SPEED ADJUST-
MENT key to select the speed 1 item.
4) Check the indicated speed level The value should be
130rpm.
¡Eject fan Speed 1 is now set to 130rpm.
If the value is not correct:
¡Use the and/or key to adjust the displayed value
to the correct value.
5) To set Speeds 2 through 4, repeat steps 2) through 4)
above, substituting the appropriate speed for Speed 1
in step 2), and making the appropriate settings given
below.
6) Settings for Speeds 2 through 5:
HELP mode H-01 \ see p.220
¡HELP mode H-01 display
¡HELP mode H-01 display
1. Pre-stop speed
2. JOG speed
3. Print speed
4. Eject fan speed
Speed level (rpm)
130 rpm 130 rpm
150 rpm 150 rpm
165 rpm 165 rpm
190 rpm 190 rpm
225 rpm 235 rpm
DP-440/430 DP-340/330
1 st speed
2 nd speed
3 th speed
4 th speed
5 th speed
Eject fan speed
2. To Initialize Speed Settings:
1) Access HELP mode H-01.
2) Press the and/or key to select the Eject fan
speed item.
3) Press the [=] and CLEAR key. The settings
will be initialized.
4) Press the STOP key. The HELP mode menu will
reappear.
¡After initialization, new speed values must be set.
NOTE :
HELP mode H-01 \ see p.220
7) Press the STOP key. The drum will stop rotating,
the settings will be memorized, and the HELP mode
selection display will reappear.
