c Paper Feed Section
chap.2
The paper feed roller is driven by the paper feed stepping motor via the timing belt. The rotational timing is
controlled by the program.
(2) Paper Feed Roller Drive
Paper feed roller
Paper feed stepping motor
Timing belt
440303
