91
n Paper Ejection Section
chap.2
2nd speed
190rpm
130rpm
150rpm
165rpm
5th speed
Description
The paper ejection belt takes the paper stripped off the drum by the paper stripper finger to the print tray.
The belt is driven by the paper ejection motor. Its speed is sensed by an eject fan encoder sensor.
1. Paper ejection belt speed
The paper ejection belt is controlled to the speed that matches the printing speed.
The belt speeds that are set for the various printing speeds are shown in the table below. The set speeds can
be adjusted using HELP01.
