n Paper Ejection Section
chap.2
nPaper Ejection Section
1. Description
In the paper ejection section the printed paper is removed from the drum and is ejected to the print tray.
Escape cam
Paper stripper finger
Paper ejection motor
Top blow fan
440323
Paper ejection fan
Eject fan encoder sensor
Paper ejection JAM
sensor(Photo-emitting)
Paper ejection JAM
sensor(Photo-receiving)
Paper ejection fan unit
Top blow fan unit
