Duplo DUPRINTER DP-430 User Manual

299
z Electrical Parts Layout and Their Functions
chap.8
3
2
1
5
4
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
(2) Sensors 1
440912
Scanner home position is detected.
Document cover position is detected.
ADF home position is detected.
Top/bottom center of the print position is detected.
Print position encoder sensor.
Paper feed elevator top limit is detected.
Main motor encoder sensor.
Paper ejection fan encoder detection.
Master clump opening and closing lever A/C mode is detected.
Master clump opening and closing lever B mode is detected.
Master set/removal position is detected.
Drum stop position and JAM detection position are detected.
Press roller ON and OFF is detected.
Pressure sensor.
Thermal head press position is detected.
Master ejection box opening and closing is detected.
Drum center position is detected.
Drum position limit sensor.
Ink roller up and down is detected.
LPU escape timing is detected.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
FunctionsItem No.
Microsensor
