52
x Platemaking / Master Feed / Ejection Section
chap.2
Description
Completed, the stepping motor for platemaking and the drum stops temporarily, the cutter motor is turned on
to drive the cutter and the master is cut.
CN1-1
-32
CN9-7
-8
Cutter motor(M5)
Black
Red
Black
Red
1
2
5
6
Drive PCB unit
-
CN3-1
-32
Main PCB unitDC-DC PCB unit
-
CN3-1
-12
-
CN3-1
-12
-
Circuit
(5) Cutter Unit
440W11e
