z Guaranteed Periodical Maintenance x Cleaning and Oiling
chap.5
184
zGuaranteed Periodical
Maintenance
(1) Cleaning
•The serviceman will visit the user periodically after delivery. The maintenance operation described in the
periodical maintenance list is performed and instructs how to follow the operation.
When the serviceman is called by telephone, the following maintenance must be performed after clearing
the trouble.
1. Cleaning the document.
2. Cleaning the document table glass.
3. Cleaning the thermal head.
xCleaning and Oiling
1.Paper shreds:
Clean with a brush or dry cloth.
Clean the mirror and reflection plate in the scanner section with a blower brush.
2.Ink:
Clean with soap.
Oil or grease after ink or paper shreds are removed.
(2) Oiling
2.Gear section:
Grease the gear section after removing paper shreds on the bottom of gear.
1.Bearing section:
Oil the edge surface and bearing sections with oiler, rotating the lever and roller.
To Next Page
