Duplo DUPRINTER DP-430 User Manual

59
x Platemaking / Master Feed / Ejection Section
chap.2
(3) Clump Opening / Closing Lever
Position (A / B / C Mode)
Mode Photointerrupter stop position / state of sensor Functions
In the normal state or during printing, the
master clump opening / closing lever turns
out from the master clump opening /
closing lever.
A
m
o
d
e
B
m
o
d
e
C
m
o
d
e
The master clump opening / closing lever
pinch the master clump opening / closing
arm.
The master clump is open. This state
occurs when the master is set or removal.
B mode sensor
(PS4)
B mode sensor
(PS4)
B mode sensor
(PS4)
A / C mode sensor (PS3)
A / C mode sensor (PS3)
A / C mode sensor
(PS3)
Photo-
interrupting
gPh
oto-passing
or
Photopassing
g Photo-
interrupting
Photo-
passing
Photo-
interrupting
Photo-interrupting
Photo-
passing
Photo-
passing
