84
b Press Section
chap.2
(2) Switching the Contact Pressure
The contact pressure can be switched on the operation panel. When it is changed on the operation panel, the
contact motor will start up to effect the switch as soon as the PRINT key is pressed.
Circuits
Brown
Purple
1
2
1
2
Pressure motor
Pressure center switch
Green
Green
1
2
M
CN12-8
-9
CN21-1
-2
Drive PCB unit
Main PCB unit
5V
Pressure position switch
White
White
3
4
-3
-4
5V
Pressure encoder sensor
Red
Blue
CN12-10
1
2
3
-12
Orange
-11
5V
5V
5V
0
1
3
2
Photopassing :0V
Photointerrupting:5V
Press roller
Pressure center
switch
Pressure motor
Pressure
encoder sensor
Pressure
position switch
440310
440W24e
