220
c HELP Mode Function and Operation Procedures
chap.7
H-01
(6) , (7) Adjustment / specification settingHELP mode
(6) Adjustment of Eject fan speeds 1-5
q
Access HELP mode H-01, and press the PRINT key.
wPress the and/or key to select the Eject fan speed item.
ePress the and/or PRINTING SPEED ADJUSTMENT
key to select the Eject fan speed item.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
tPress the STOP key.
The HELP mode selection display will reappear.
rCheck the indicated speed level.
HELP-001
Speed check
r p m111
1. Pre-stop speed
2. JOG speed
3. Print speed
4. Eject fan speed
Speed level (rpm)
(7) Initialization of Eject fan speeds
q
Access HELP mode H-01, and press the PRINT key.
wPress the and/or key to select the Eject fan speed item.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
ePress the [=] and CLEAR keys.
The settings will be initialized.
¡After initialization, the speeds 1-5 must be readjusted.
IMPORTANT :
HELP-001
Speed check
r p m111
1. Pre-stop speed
2. JOG speed
3. Print speed
4. Eject fan speed
Speed level (rpm)
¡During memorization:
- SAVE -
2
Use the and/or key to adjust the displayed value to
within the recommendation.
If the indicated value does not accord with the recommended value above ?
-+
DP-440/430 DP-340/330
Speed 1 : 130rpm Speed 1 : 130rpm
Speed 2 : 150rpm Speed 2 : 150rpm
Speed 3 : 165rpm Speed 3 : 165rpm
Speed 4 : 190rpm Speed 4 : 190rpm
Speed 5 : 225rpm Speed 5 : 235rpm
Recommendation
