225
c HELP Mode Function and Operation Procedures
chap.7
2. Operation procedure
Accessing HELP modes
a
See page 213
H-05
(1) Sensor / switch condition displayHELP mode
(1) Checking the condition of the displayed sensors
q
Access HELP mode H-05, and press the PRINT key.
wPress the and/or key to select the sensor item.
HELP-005
1 : Scanner home position sensor
1 : Document cover position sensor
1 : ADF home position sensor
1 : Top/bottom center sensor
1 : (Not used)
1 : Top/bottom encoder sensor
1 : Elevator top limit sensor
1 : Paper detection sensor
1 : Main motor encoder sensor
1 : Eject fan encoder sensor
1 : A/C mode detection sensor
Sensors
HELP-005
1 : B mode detection sensor
1 : Master set/removal position sensor
1 : Drum stop/JAM detection position sensor
1 : P-roller sensor
1 : Pressure encoder sensor
1 : Thermal head position sensor
1 : Master lead edge sensor
1 : Ejection box sensor
1 : Drum center sensor
1 : Drum limit sensor
1 : Ink roller up/down sensor
Sensors
HELP-005
1 : Signal sensor
1 : G-roller sensor
1 : Document sensor 1 (scanner)
1 : Document sensor 2 (scanner)
1 : Document sensor 3 (scanner)
1 : Document sensor 4 (scanner)
1 : Document sensor 5 (scanner)
1 : Document sensor (ADF)
1 : Document JAM sensor (ADF)
Sensors
Value
Value
Value
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
ePress the STOP key.
The HELP mode selection display will reappear.
