231
c HELP Mode Function and Operation Procedures
chap.7
H-09
(1) Function testingHELP mode
1. Functions
(1)
Master set/ JAM/ Master removal/ Drum stop position
can be checked
¡
Following items are checked.
1. Master set position
2. JAM sensing position
3. Master removal position
4. Drum stop position
2. Operation procedure
Accessing HELP modes
a
See page 213
(1) Master set/ JAM/ Master removal/ Drum stop
position can be checked
q
Access HELP mode H-09, and press the PRINT key.
¡Each time the PRINT key is pressed, the drum stop and
jam sensing position sensors, and the master removal /set
positions sensors, will alternately sense the edge of the
shade plate, then stop.
a
To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
wPress the STOP key.
The HELP mode selection display will reappear.
HELP-009
Master set/JAM/master removal/
drum stop position can be checked.
Movement test
drum stop position
