m Option
chap.1
28
mOption
1. DUPRINTER Option
(1) TAPE CLUSTER 4
23S0029
23S0030
23S0031
43SH0104
1cm
q
Open out the tape cluster body.
w
Install the new tape. Make sure it will wind off in the
correct direction.
e
Lift up the lever and pass the tape through the slot.
r
Make about 1cm of tape protrude out of the slot.
t
Swing the tape cluster body back in.
Lever
Tape
Tape cluster body
