C
HAPTER
5
| Interface Configuration
Trunk Configuration
– 145 –
LACPDUs Interval Number of seconds before invalidating received LACPDU information.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
â—†
Expired – The actor’s receive machine is in the expired state;
â—†
Defaulted – The actor’s receive machine is using defaulted
operational partner information, administratively configured for
the partner.
â—†
Distributing – If false, distribution of outgoing frames on this link
is disabled; i.e., distribution is currently disabled and is not
expected to be enabled in the absence of administrative changes
or changes in received protocol information.
â—†
Collecting – Collection of incoming frames on this link is enabled;
i.e., collection is currently enabled and is not expected to be
disabled in the absence of administrative changes or changes in
received protocol information.
â—†
Synchronization – The System considers this link to be IN_SYNC;
i.e., it has been allocated to the correct Link Aggregation Group,
the group has been associated with a compatible Aggregator, and
the identity of the Link Aggregation Group is consistent with the
System ID and operational Key information transmitted.
â—†
Aggregation – The system considers this link to be aggregatable;
i.e., a potential candidate for aggregation.
â—†
Long timeout – Periodic transmission of LACPDUs uses a slow
transmission rate.
â—†
LACP-Activity – Activity control value with regard to this link.
(0:Passive;1:Active)
Table 7: LACP Internal Configuration Information (Continued)
Parameter Description
