– 411 –
16 IP CONFIGURATION
This chapter describes how to configure an IP interface for management
access to the switch over the network. This switch supports both IP Version
4 and Version 6, and can be managed simultaneously through either of
these address types. You can manually configure a specific IPv4 or IPv6
address or direct the switch to obtain an IPv4 address from a BOOTP or
DHCP server when it is powered on. An IPv6 address can either be
manually configured or dynamically generated.
This chapter provides information on network functions including:
◆ Ping – Sends ping message to another node on the network.
◆ IPv4 Configuration – Sets an IPv4 address for management access.
◆ IPv6 Configuration – Sets an IPv6 address for management access.
USING THE PING FUNCTION
Use the IP > General > Ping page to send ICMP echo request packets to
another node on the network.
CLI REFERENCES
â—† "ping" on page 921
PARAMETERS
These parameters are displayed:
◆ IP Address – IP address of the host.
◆ Probe Count – Number of packets to send. (Range: 1-16)
◆ Packet Size – Number of bytes in a packet. (Range: 32-512 bytes)
The actual packet size will be eight bytes larger than the size specified
because the switch adds header information.
COMMAND USAGE
â—† Use the ping command to see if another site on the network can be
reached.
â—† The following are some results of the ping command:
â–
Normal response - The normal response occurs in one to ten
seconds, depending on network traffic.
