Edwards HemoSphere User Manual

11
143
Oximetry Monitoring
Contents
Oximetry Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143
In Vitro Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144
In Vivo Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
Signal Quality Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Recall Oximetry Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
HGB Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
HemoSphere Oximetry Cable Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
New Catheter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
11.1 Oximetry Setup
Refer to the directions for use provided with each catheter for specific instructions on catheter placement
and use, and for relevant warnings, cautions and notes. The HemoSphere oximetry cable must be calibrated
before monitoring.
1 Connect the HemoSphere oximetry cable to the HemoSphere advanced monitor. The following
message will appear:
Oximetry Initializing, Please Wait
2 If the HemoSphere advanced monitor is not on, turn on the power switch and follow steps for
entering patient data. See Patient Data on page 88.
3 Remove a section of the catheter tray lid to expose the optical connector.
4 Insert the optical connector of the catheter “TOP” side up into the oximetry cable and snap the
enclosure shut.
Status = Released Printed Date: 2018-01-16 Released Date: 2017-09-14

Edwards HemoSphere Specifications

General

Technology	Advanced hemodynamic monitoring
Connectivity	Ethernet, USB
Power Supply	100–240 VAC, 50/60 Hz
Parameters Measured	Cardiac output, stroke volume, systemic vascular resistance
Trending	Yes
Alarms	Configurable alarms for various parameters
Data Storage	Internal memory
Applications	Critical care
Display	Touchscreen
