HemoSphere Advanced Monitor 4 HemoSphere Advanced Monitor Quick Start
21 Touch the Accept button.
4.1.3 Continuous End Diastolic Volume Monitoring
Follow steps 1-10 at the start of section 4.1 before proceeding.
11 Attach the thermistor and thermal filament Swan-Ganz volumetric catheter connections
(figure 4-1) to the patient CCO cable.
12 Verify that the catheter is properly inserted into the patient.
13 Connect one end of the ECG interface cable to the rear panel of the HemoSphere advanced
monitor and the other end to the bedside monitor’s ECG signal output.
14 Touch the start monitoring icon to begin CO/EDV monitoring.
15 A countdown clock will appear on the stop monitoring icon to indicate the time until the
first CO/EDV value. After approximately 6 to 9 minutes, when sufficient data has been obtained,
an EDV and/or RVEF value will appear in the configured parameter globe(s).
16 The time until the next CO measurement is displayed on the information bar. For longer time
spans between calculations, select STAT parameters (sCO, sEDV, and sRVEF) as key parameters.
sCO, sEDV, and sRVEF are fast estimates of CO, EDV, and RVEF.
17 Touch the stop monitoring icon to stop CO/EDV monitoring.
