Edwards HemoSphere User Manual

13
168
Troubleshooting
Contents
On Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Monitor Status Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Pressure Cable Communication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
HemoSphere Advanced Monitor Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
HemoSphere Swan-Ganz Module Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Pressure Cable Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181
Oximetry Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .186
13.1 On Screen Help
The main help screen allows the user navigate to specific help for HemoSphere advanced monitoring
platform issues. Faults, alerts and warnings notify the user of error conditions affecting parameter
measurements. Faults are technical alarm conditions that suspend parameter measurement. The category
help screen provides specific assistance for faults, warnings, alerts, and troubleshooting.
1 Touch the settings icon .
2 Touch the Help button to access the main help screen.
3 Touch the category help button corresponding to the technology for which help is needed:
Monitor, Swan-Ganz Module, Pressure Cable, or Oximetry.
4 Touch the type of help needed based on the message type: Faults, Alerts, Warnings, or
Troubleshooting.
5 A new screen appears with a list of the selected messages.
6 Touch a message or troubleshooting item from the list and touch Select to access information for
that message or troubleshooting item. To view the full list, use the arrow buttons to move the
selection highlight up or down the list. The next screen displays the message along with possible
causes and suggested actions.
Status = Released Printed Date: 2018-01-16 Released Date: 2017-09-14

Edwards HemoSphere Specifications

General

Technology	Advanced hemodynamic monitoring
Connectivity	Ethernet, USB
Power Supply	100–240 VAC, 50/60 Hz
Parameters Measured	Cardiac output, stroke volume, systemic vascular resistance
Trending	Yes
Alarms	Configurable alarms for various parameters
Data Storage	Internal memory
Applications	Critical care
Display	Touchscreen
