Installation and Setup
Contents
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
HemoSphere Advanced Monitor Connection Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
HemoSphere Advanced Monitor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Initial Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.1 Unpacking
Examine the shipping container for any signs of damage that may have occurred during transit. If any
damage is detected, photograph the package and contact Edwards technical support for assistance. Perform
a visual inspection of the packaging contents for damage. Damage may include cracks, scratches, dents or
any signs that the monitor, modules or cable housing may be compromised. Report any evidence of external
damage.
3.1.1 Packaging Contents
The HemoSphere advanced monitoring platform is modular and therefore packaging configurations will
vary depending upon the kit ordered. The HemoSphere advanced monitoring system, which is the base kit
configuration, contains the HemoSphere advanced monitor, mains power cord, power entry cover,
HemoSphere battery pack, two expansion modules, one L-Tech expansion module, a quick start guide and
a USB stick containing this operator’s manual. See table 3-1. Additional items that may be included and
shipped with other kit configurations include the HemoSphere Swan-Ganz module, patient CCO cable, and
HemoSphere oximetry cable. Disposable and accessory items may be delivered separately. It is
recommended that the user confirm the receipt of all ordered equipment. Refer to appendix B: Accessories,
for a full list of available accessories.
Table 3-1 HemoSphere advanced monitoring components
HemoSphere advanced monitoring system (base kit)
• HemoSphere advanced monitor
• HemoSphere battery pack
• mains power cord
• power entry cover
• L-Tech expansion module
• expansion module (2)
• quick start guide
• operator’s manual (on USB stick)
Status = Released Printed Date: 2018-01-16 Released Date: 2017-09-14

Edwards HemoSphere Specifications

General

Technology	Advanced hemodynamic monitoring
Connectivity	Ethernet, USB
Power Supply	100–240 VAC, 50/60 Hz
Parameters Measured	Cardiac output, stroke volume, systemic vascular resistance
Trending	Yes
Alarms	Configurable alarms for various parameters
Data Storage	Internal memory
Applications	Critical care
Display	Touchscreen
