HemoSphere Advanced Monitor A Specifications
A.3 HemoSphere Battery Pack Specifications
HRavg display CO Monitoring Off. Averaging time: 57 seconds; Update rate: Per
beat; Response time: 40 seconds for step increase from 80 to 120
BPM, 29 seconds for step decrease from 80 to 40 BPM.
CO Monitoring On. Averaging time: Time between CO
measurements (3 to 21 minutes); Update rate: Approximately 1
minute; Response time: 175 seconds for step increase from 80 to
120 BPM, 176 seconds for step decrease from 80 to 40 BPM.
Electrical
Rated supply voltage 100 to 240 Vac; 50/60 Hz
Rated input 1.5 to 2.0 Amps
Fuses T 2.5AH, 250V; High breaking capacity; Ceramic
Alarm
Sound pressure level 45 to 85 dB(A)
Wireless
Type connection to Wi-Fi networks that are compliant to 802.11b/g/n,
minimum
Table A-5 HemoSphere battery pack physical specifications
HemoSphere battery pack
Weight 0.9 lbs (0.4 kg)
Dimensions Height 1.38 in (35 mm)
Width 3.15 in (80 mm)
Depth 5.0 in (126 mm)
Table A-6 HemoSphere battery pack environmental specifications
Environmental specification Value
Temperature
Operational 10 to 37 °C
Recommended storage 21 °C
Maximum long
term storage 35 °C
Minimum long term storage 0 °C
Relative humidity
Operational 5 to 95% non-condensing at 40 °C
Table A-7 HemoSphere battery pack technical specifications
Specification Value
Output voltage (nominal) 12.8 V
Maximum discharge current 5 A
Cel
ls 4 x LiFePO
4
(lithium iron phosphate)
Capacity 3150 mAh
Table A-4 HemoSphere advanced monitor technical specifications (continued)
Input/Output (continued)
