HemoSphere Advanced Monitor A Specifications
A.4 HemoSphere Swan-Ganz Module Specifications
Table A-8 HemoSphere Swan-Ganz module physical specifications
HemoSphere Swan-Ganz module
Weight approximately 1.0 lbs (0.45 kg)
Dimensions Height 1.36 in (3.45 cm)
Width 3.53 in (8.96 cm)
Depth 5.36 in (13.6 cm)
Table A-9 HemoSphere Swan-Ganz module parameter measurement specifications
Parameter Specification
Continuous Cardiac Output
(CO)
Range 1 to 20 L/min
Reproducibility
1
±6% or 0.1 L/min, whichever is greater
Average response time
2
<10 mins (for CCO catheters)
<14 mins (for CCO volumetric catheters)
Intermittent (Bolus) Cardiac
Output (iCO)
Range 1 to 20 L/min
Reproducibility
1
±3% or 0.1 L/min, whichever is greater
Blood Temperature (BT) Range 15 to 45 °C
(59 to 113 °F)
Accuracy ±0.3 °C
Injectate Temperature (IT) Range 0 to 30 °C
(32 to 86 °F)
Accuracy ±1 °C
Average Heart Rate for EDV/
RVEF Determination (HRavg)
Acceptable input range 30 to 200 bpm
Continuous Right Ventricular
Ejection Fraction (RVEF)
Range 10 to 60%
Reproducibility
1
±6% or 3 efu, whichever is greater
1
Coefficient of variation — measured using electronically generated data
2
10 to 90% change under conditions of stable blood temperature
