HemoSphere Advanced Monitor 3 Installation and Setup
3.1.2 Required Accessories for Platform Modules and Cables
The following tables identify accessories required to display specific monitored and calculated parameters
for the specified hemodynamic technology module or cable:
NOTE Not all parameters can be monitored or calculated in pediatric patients. See table 1-1 on
page 19 for available parameters.
*NOTE A CVP analog input signal or CVP manual entry is needed to calculate SVR.
Table 3-2 Cables and catheters required for monitoring parameters with HemoSphere
Swan-Ganz module
Monitored and calculated parameters
Required cable/catheter CO EDV RVEF SVR iCO SV
patient CCO cable
••••••
ECG cable
•• •
analog pressure input cable(s)
•
injectate temperature probe
•
Swan-Ganz thermodilution catheter
•
Swan-Ganz CCO catheter or Swan-
Ganz CCOmbo catheter
• •••
Swan-Ganz CCOmbo V catheter
••••••
Table 3-3 Sensor options for monitoring parameters with HemoSphere pressure cable
Monitored and calculated parameters
Pressure sensor/
transducer options
(one required)
CO SV SVV SVR PR SYS/
DIA/
MAP
MPAP CVP P(↓BP)
FloTrac sensor
•••*••
TruWave transducer
••••
FloTrac IQ sensor
•••*•• •
Table 3-4 Catheters required for monitoring parameters with HemoSphere oximetry
cable
Monitored and
calculated
parameters
Required catheter ScvO
2
SvO
2
PediaSat oximetry catheter or compatible
central venous oximetry catheter
•
Swan-Ganz oximetry catheter
•
