X-STREAM
Emerson Process Management GmbH & Co. OHG9-6
Instruction Manual
HASAxE-IM-HS
05/2006
9-3 Modbus - List of Parameters and Registers
Attribute
1
Daniel /
Enron
Modicon Type
Range / Enum values / Coefficients
Modbus-Register
Mnemonic
Description
2029 2029
dbAcknowledgeStates()
acknowledge all status messages
Fct
2007 = 1 2007 = 1
dbCalibCommand (CAL_ZERO_SPAN_1_2,…)
start zero&span calibration of all channels
Fct
2001 = 0
2007 = 0
2001 = 0
2007 = 0
dbCalibCommand (CALCMD_CANCEL, ..)
cancel a running calibration
Fct
2003 = 1
2004 = 1
2003 = 1
2004 = 1
dbCalibCommand (CALCMD_SPAN_#,…)
start span calibration of a channel
Fct
2006 = 1 2006 = 1
dbCalibCommand (CALCMD_SPAN_1_2,…)
start span calibration of all channels
Fct
2001 = 1
2002 = 1
2001 = 1
2002 = 1
dbCalibCommand (CALCMD_ZERO_#,…)
start zero calibration of a channel
Fct
2005 = 1 2005 = 1
dbCalibCommand (CALCMD_ZERO_1_2,…)
start zero calibration of all channels
Fct
2028 2028
dbResetDevice()
reset the device (warm start)
Fct
Boolean
2033 = 1
2034 = 1
2033 = 1
2034 = 1
dbRestoreCalib (CALCMD_SPAN_#,…)
restore span calibration data of a channel from
user data memory
Fct
2031 = 1
2032 = 1
2031 = 1
2032 = 1
dbRestoreCalib (CALCMD_ZERO_#,…)
restore zero calibration data of a channel from
user data memory
Fct
3109 = 2 3109 = 2
dbStoreData2FLASH (.., FL_PARA_USER)
save configuration data to user memory
Fct
3109 = 3 3109 = 3
dbStoreData2FLASH(..,FL_PARA_FACT)
save configuration data to factory memory
Fct
2011 = 1/0
2012 = 1/0
2011 = 1/0
2012 = 1/0
dbSwitchValves (VALVE_SAMPLEGAS)
switch on/off sample gas valve
Fct
2015 = 1/0
2016 = 1/0
2015 = 1/0
2016 = 1/0
dbSwitchValves (VALVE_SPANGAS#)
switch on/off span gas valve of channel
Fct
2013 = 1/0
2014 = 1/0
2013 = 1/0
2014 = 1/0
dbSwitchValves (VALVE_ZEROGAS)
switch on/off zero gas valve
Fct
This list is ordered alphabetically by the parameter name („Mnemonic“) column.
Any "#" is a wildcard, to be replaced by "1" or "2" for the desired measuring channel. In this case
the upper register line is assigned to channel 1, the lower line to channel 2.
