CR Console Operation Manual
2010. 10 897N0519K 2 - 23
EI/DI display field
: When an image is displayed (or is selected in six-image
display mode), the EI and DI (defined in IEC 62494-1: 2008)
are displayed.
The EI and DI can be displayed only for normal images
(except mammography images). They do not appear for
energy subtraction images, long-view images, etc. When an
image is replaced with other one, the values are updated
accordingly.
The EI/DI display field can be repositioned by moving the
□
mark.
Whether the EI/DI display field is displayed or not depends
on the setting made at the time of installation.
NOTES
•
In case that a cassette-type Image Reader is used, the EI
and DI values are displayed properly only when the type
of the IP is ST-VN, ST-VI, or ST-BD.
•
When using the EI and DI values for image quality
management, calibrations of Image Readers should be
carried out periodically.
•
The EI and DI may vary if a wrong exposure menu was
selected.
Exposure menu list
: This list shows exposure menus selected on the
(one-image display)
“Exposure Menu Selection Screen”. Moving up and down
the “Exposure menu list” with any exposure menus selected
accordingly will allow you to change order of selected
exposure menus.
: Displays a menu for which the patient information is modified.
: Adds exposure menus and displays the “Exposure Menu Addition box”.
:
Changes exposure menus and displays the “Exposure Menu Change box”.
: Performs auto-repeat exposure. Exposures can be performed repeatedly using the
exposure menu same as the selected one.
: Handles a read image as a rejected one.
: Adds the same exposure menu as the selected one.
:
Deletes exposure menus.
/
: Scrolls the exposure menu list in one-image display mode and the image display field
in six-image display mode.
: Before exposure (image reading session), checks and changes, as necessary, exposure
parameters used for the exposure menu. The exposure parameter selection box is
displayed.
: Changes film format. The format change is possible either before or after image
reading.
: Displays images in monitor mode.
: Switches display mode alternately to six-image display mode.
NOTE
In six-image display mode, only up to 18 exposure menus can be displayed.
:
Edits image information.
To Next Page
