Table 7-18
Inactive/hot addition work procedure (for an internal disk or PCIe card)
Item Work procedure Reference
1 Opening the rack door
2 Switching the mode switch on the
operation panel to Service mode
"5.2 Switching the Mode Switch to Service Mode"
3 Checking the operating condition
of the system and the I/O device
usage status
"5.3 Checking the Operating Condition and Resource Usage Status"
4 Powering off the chassis requiring
maintenance
"
5.5 Powering Off the Physical Partition Requiring Maintenance"
5Lowering the cable support for
maintenance on a PCIe card
"5.9.2 Lowering the cable support"
6 Installing the target FRU See the installation procedures for each FRU.
"Chapter 8 Maintaining the PCI Express Cards"
"Chapter 10 Maintaining the Internal Disks"
7 Securing the cable support
after
maintenance on a PCIe card
"6.1.2 Fixing the cable support"
8 Diagnosing the installed FRU "6.3.1 Diagnosing the system board"
9Confirming that there is no
problem with the installed FRU
"4.2.2 Identifying a failure" - "Checking the FRU status"
10 Returning the mode switch on the
operation panel to Locked mode
"
6.6 Returning the Mode Switch to Locked Mode"
11 Powering on the chassis requiring
maintenance
"6.7 Powering On the Physical Partition Requiring Maintenance"
12 Closing the rack door
