Table 7-21
System-stopped/cold addition work procedure (for a single-chassis configuration)
Item Work procedure Reference
1 Opening the rack door
2 Switching the mode switch on the
operation panel to Service mode
"5.2 Switching the Mode Switch to Service Mode"
3 Checking the operating condition
of the system and the I/O device
usage status
"5.3 Checking the Operating Condition and Resource Usage Status"
4 Stopping the system "5.6 Stopping the Entire
System"
5 Enabling maintenance of the
chassis requiring maintenance
"5.9 Accessing an FRU"
6 Installing the target FRU See the installation procedures for each FRU (Chapters 8 to 10).
"Chapter 8 Maintaining the PCI Express Cards"
"Chapter 9 Maintaining the CPU Memory Unit/Memory"
"Chapter 10 Maintaining the Internal Disks"
7Restoring the chassis
requiring
maintenance
"6.1 Restoring the Chassis"
8 Performing a diagnosis test "6.3.1 Diagnosing the system board"
9Confirming that there is no
problem with the installed FRU
"4.2.2 Identifying a failure" - "Checking the FRU status"
10 Returning the mode switch on the
operation panel to Locked mode
"6.6 Returning the Mode Switch
to Locked Mode"
11 Starting the system "6.8 Starting the Entire System"
12 Closing the rack door
