1. Open rack door
4. Release chassis requiring maintenance from
partition
6. Enable access to FRU requiring maintenance
5. Release chassis requiring maintenance from
system
7. Remove FRU for removal
8. Restore chassis requiring maintenance
9. Incorporate chassis requiring maintenance
into system
12. Confirm that there is no problem with
chassis after removal
13. Restore logical domain
14. Close rack door
Removal complete
3. Release assignment of PCIe card
2. Check operating condition of system and
I/O device usage status
11. Incorporate chassis requiring maintenance
into partition
10. Diagnose chassis requiring maintenance
Figure 7-24
Active/cold removal flow (building block configuration only)
