7.
Raise
the
levers
(A
in
the
figure)
on
the
right
and
left
sides
to
release
the
CPU
memory
unit
upper.
Figure
9-15
　　
Positions
of
right
and
left
levers
8.
While
holding
the
levers,
slightl y
lift
the
CPU
memory
unit
upper.
9.
If
PCIe
cables
are
connected
to
the
CPU
memory
unit
lower
that
has
a
filler
unit
mounted,
push
the
PCIe
cables
(A
and
B
in
the
figure)
toward
the
outside
of
the
chassis.
Chapter
9
　
Maintaining
the
CPU
Memory
Unit/Memory 199
