B
A
Note -
Be careful when removing the CPU memory unit upper or the filler unit so that it does
not catch on any PCIe cable.
Note -
Place the removed CPU memory unit upper on a grounded antistatic ESD mat.
Figure 9-16
How to push PCIe cables toward the outside
10.
With a hold on the Handling Position on both sides of the CMUU, lift the CPU
memory unit upper or filler unit, and then remove it carefully.
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014200
