A
B
B
C
D
Figure 9-28
Removing the XSCF mount (for the SPARC M10-4S with a FRAME-A
CPU memory unit)
-
For the SPARC M10-4 with a FRAME-B CPU memory unit
Slide the right side of the XSCF mount (A in the figure) by about 8 mm (0.4 in.)
toward the front (B in the figure).
Then, pull it upward to remove it (C in the
figure).
Chapter 9 Maintaining the CPU Memory Unit/Memory 211
